Specialized in Manufacturing Corrugated Carton Printing Machine & Solutions Since 1995

Guangzhou Keshenglong Carton Packing Machine Co.,Ltd.

3 Colour Corrugated Carton Flexo Printing Machinery Sale in China

High speed corrugated paperboard 4 colour flexo printing machine of our "JUMBO", the max mechanic speed can reach 120 pieces per minute.
  • Item NO.:

    K1
  • Lead Time:

    3-5 months
  • Product Orgin:

    China
  • Brand:

    Keshenglong
  • Shipping Port:

    Guangzhou/Shenzhen
  • Payment:

    L/C, T/T
  • Price Range:

    400000-2000000/1$
Inquiry now
Details

3 Colour Corrugated Carton Flexo Printing Machinery Sale in China


Corrugated 4 Color Carton Flexo Printing Machine Features:

·This machine is designed and made to high quality and safety standard,with the advantages of high speed, auto     control and quick order shift.

·Auto high quality materials and parts.

·Well hardened and ground transmission gears, hardness more than 60(HRC).

·Auto zero return and auto reset.

·Use expansion sets tight link to reduce abrasion of the shaft,keep precision of the machine for long years.

·All cylinders and rollers are chromed plated for ideal hardness.

·PLC control system with touch screen control.

·Able to save order,speed up the order shift.

·All electronic and pneumatic components are with European standards.

·Lead edge feeder or kick feeder is for choice.


3 Color Flexo Printing Machine Specification:

Data                             Model

1600×3600

2200×3600

2600×3600

2600×4300

Max. mechanic speed(pcs/min)

120

100

80

80

Max. feeding size(mm)

1570×3600

2100×3600

2500×3600

2500×4300

Min. feeding size(mm)

420×750

550×900

650×900

650×900

Max. printing area(mm)

1540×3600

2080×3600

2480×3600

2480×4300

Max. thickness of board(mm)

7.2

7.2

7.2

7.2

Min.slotting space(mm)   slotting type L(mm)

260×90×260×90

330×110×330×110

360×110×360×110

360×110×360×110

Max. slot depth(mm)

560

750

850

850

Max. thickness of board(mm)

12

12

12

12

WeightkgT

F

46000

53500

72500

83000

76500

88000

8950

104000

Dimension(L×W×H)(mm)T

F

14021×6755×3500

14701×6755×3500

19122×6755×3600

20046×6755×3600

20237×6755×3600

21261×6755×3600

20237×6755×3600

21261×6755×3600


4 Color Corrugated Carton Box Flexo Printing Machines Advantages:

1.CNC control system (Intelligent Control)

2.Environmental Protection and Energy Saving, use washable ink;

3.Apply to box for big household appliances such as refrigerator, air-conditioner, and heavy industrial box, such as      motorbike, auto spare parts.

4.Able to print and make honeycomb box.


Our Team:

For the time being, we have more than 300 employees in our team, and have our own R&D, manufacturing, sales and after-sales service department, with our strict production and experienced construction team, taking the professional route and providing one-stop service for our customers.
