4 Color Flexo Printer Slotter Machine
Flexo Printer Die Cutter Slotter Carton Features：
·This flexo printer inline with foler gluer is designed and made to high quality and safety standard,with the advantages of high speed, auto control and quick order shift.
·Computerized control,order setting in touch screen.
·The Folding Section adopts belt transfer system assisted with vacuum suction,to make best transfering and folding quality.
·The Gluing Section adopts U.S.A VALCO high speed auto-sensor glue spray system.
·The correction device in the Countering Section can conquer the fish-tail,makes the carton even.
·The quantity of bundle come out from the Counter Ejector can be set in touch screen.
·All electronic and pneumatic components are with European standards.
Corrugated Printer Specification：
320x700
Dimension(LxWxH) T
F
T:18832×4750×2800
F:19552×4750×2800
T:18832×5150×2800
F:19550×5150×2800
T:20255×4870×2800
F:20975×4870×2800
T:20255×5270×2800
F:20975×5270×2800
T:20255×5670×2800
F:20975×5670×2800
T:23110×5690×3000
F:23830×5690×3000
T:23110×6090×3000
F:23830×6090×3000
T:23110×6490×3000
F:23830×6490×3000
Data/Model
900x2000
900x2400
1200x2000
1200x2400
1200x2800
1600x2800
1600x3200
1600x3600
Printing Speed(m/min)
200
200
200
200
200
200
200
160
Max Machine Speed(pcs/min)
350
300
250
250
220
200
150
120
Max Feeding Size(mm)
880x2000
880x2400
1180x2000
1180x2400
1180x2800
1540x2800
1570x3200
1570x3600
Min Feeding Size(mm)
280x640
280x640
320x700
320x700
420x760
420x760
420x760
Skip Feeding(mm)
1100x2000
1100x2400
1500x2000
1500x2400
1500x2800
1900x2800
1900x3200
1900x3600
Max Printing Area(mm)
800x2000
800x2400
1150x2000
1150x2400
1150x2800
1540x2800
1540x3200
1540x3600
Thickness of Printing Plate(mm)
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
Min Panel(mm) Slot Type L.
240x80x240x80
240x80x240x80
260x90x260x90
260x90x260x90
260x90x260x90
280x100x280x100
280x100x280x100
280x100x280x100
Max Slotting Depth(mm)
250
250
320
320
320
560
560
560
Min Folding Size(mm)
280x760
280x760
320x800
320x800
320x800
420x840
420x840
420x840
Max Thickness of Sheet(mm)
8
8
12
12
12
12
12
12
Our Company:
Guangzhou Keshenglong Carton Packing Machine Co.,Ltd., is one of the leading manufacturers in China, specialized in manufacturing of carton printing and packaging machinery. And our products have been exported to more than 70 countries.
