Specialized in Manufacturing Corrugated Carton Printing Machine & Solutions Since 1995

English

Guangzhou Keshenglong Carton Packing Machine Co.,Ltd.

Corrugated Box Flexo Printing Machine with CE

4 Color Flexo Printing Machine for Carton

k6 corrugated carton box flexo printing machine , our hot selling HD flexo printing slotting machine in Keshenglong.

Item NO.:
k6
Lead Time:
3-5 months
Product Orgin:
China
Brand:
Keshenglong
Shipping Port:
Guangzhou/Shenzhen
Payment:
L/C, T/T

Inquiry now

Details

4 Color Flexo Printing Machine for Carton

Cardboard Sheets Flexo Printing Machine Features：

·This machine is designed and made to high quality and safety standard,with the advantages of high speed, auto control and quick order shift.

·Auto high quality materials and parts.

·Well hardened and ground transmission gears, hardness more than 60(HRC).

·Auto zero return and auto reset.

·All gaps between cylinders and rollers are computerized and/or motorized control.

·Vacuum transfer system used in all printing sections.

·Use expansion sets tight link to reduce abrasion of the shaft,keep precision of the machine for long years.

·All cylinders and rollers are chromed plated for ideal hardness.

·PLC control system with touch screen control.

·Able to save order,speed up the order shift.

·All electronic and pneumatic components are with European standards.

·Able to facilitate the production management.

Carton Printing Machine Flexo Specification：

Data/Model	900x2000	900x2400	1200x2000	1200x2400	1200x2800	1400x2400	1400x2800	1600x2800	1600x3200
Printing Speed(m/min)	200	200	200	200	200	200	200	200	200
Max Machine Speed(pcs/min)	300	300	250	250	220	220	200	200	180
Max Feeding Size(mm)	880x2000	880x2400	1180x2000	1180x2400	1180x2800	1380x2400	1380x2800	1540x2800	1570x3200
Min Feeding Size(mm)	280x640	280x640	320x700	320x700	320x700	350x700	350x700	420x760	420x760
Skip Feeding(mm)	1100x2000	1100x2400	1500x2000	1500x2400	1500x2800	1700x2400	1700x2800	1900x2800	1900x3200
Max Printing Area(mm)	800x2000	800x2400	1150x2000	1150x2400	1150x2800	1320x2400	1320x2800	1540x2800	1540x3200
Thickness of Printing Plate(mm)	7.2	7.2	7.2	7.2	7.2	7.2	7.2	7.2	7.2
Min Panel(mm) Slot Type L.	240x80x240x80	240x80x240x80	260x90x260x90	260x90x260x90	260x90x260x90	260x90x260x90	260x90x260x90	280x100x280x100	280x100x280x100
Max Slotting Depth(mm)	250	250	320	320	320	320	320	560	560
Max Thickness of Sheet(mm)	8	8	12	12	12	12	12	12	12
Dimension(LxWxH) T F	T:11659X4240X3200 F:12079x4240x3200	T:11659X4800X3200 F:12079x4800x3200	T:13015X4400X3500 F:13550x4400x3500	T:13015X4800X3500 F:13550x4800x3500	T:13015X5220X3500 F:13550x5220x3500	T:13570X4830X3500 F:14028x4820x3500	T:13570X5220X3500 F:14028x5220x3500	T:14021X5220X3500 F:14071x5220x3500	T:14021X5719X3500 F:14071x5719x3500

7 Color Flexo Printing Machine Advantages:

1.CNC control system (Intelligent Control)

2.Environmental Protection and Energy Saving, use washable ink;

3.Printing accuracy can be ±0.15-±0.3mm;

4.Printing plate can be 90-130LPI;

5.Varnishing and die-cutting unit are available.

Why Choose Us?

1.More than 23 years professional experience in designing and manufacturing.
2.Accept customized design according to customers' requirements.
3.High levels of performance,quality and reliability of all equipment.
4.Reliable quality proven by customers both at home and abroad.
5.Reasonable prices.
6.Promptness in both equipment delivery and technical support.
